1. Simplify fault diagnosis and maintenance
2, suitable for harsh environment
3, no wear and mechanical wear
4. Local reset function
5, achieve PL e performance level with fewer components
1. Eden safety sensor easily reaches PLe
2, low/high level coding sensor
3, 360?? installation
4. Local reset button
5, a wide range of information signals and instructions, easy to fault diagnosis and maintenance
6. Obtain the status information through the StatusBus
Eden is a non-contact safety sensor that is primarily used Interlocking devices for doors, Windows, etc., and safety positions Surveillance.
Eden consists of two parts: Adam and Eva. Adam can.
Sense the presence of Eva without mechanical contact, nor does nature There will be wear and tear.Eden is compact, can be installed 360??, easy to use, Suitable for almost all applications.
Eden can provide different types of control modules The same model. Compared to other solutions, all Model Eden products can still achieve PLe performance in series Level.
The shell seal protection of all Eden products is accessible To IP67/IP69K| Operating Temperature | -40 ℃... +70 ℃ (Storage/working) |
|---|---|
| Protection Level | IP67 and IP69K |
| Humidity Range | 35 to 85% (no freezing, no condensation) |
| Shell | Polybutylene Terephthalate (PBT) |
| Mold | Epoxy Resin |
| Weight | Eva: 70g, Adam: 80g |
| Ensure Release Distance (Sar) | 25 mm |
| Ensure Working Distance (Sao) | 10 mm |
| Rated Working Distance (Sn) | 15 2 mm |
| Recommended Distance between Adam and Eva | 7 mm |
| Minimum Distance between two Edens | 100 mm |
