Miniature design
Easy to use
Clearly visible LEDs for Power ON, switching state and weak
signal indication
Very bright, highly visible light spot
Full metal thread mounting
Not sensitive to ambient light
Optimized for small distances to any reflector
Mounting optical reflective films down to a distance of 20 mm
possible
Retroreflective sensor with polarization filter, plastic housing, 3 m detection range, red light, sensitivity adjuster, light/dark on, DC version, NPN output, fixed cable
Reflector type photoelectric sensor with polarization filter, plastic housing, 3 m detection range, red light, adjustable sensitivity, bright/dark pass, DC type, NPN output, fixed cable
| Effective Detection Distance | 0...2.7 m |
|---|---|
| Reflector Distance | 0.02...2.7 m (0.02...1 m on the OFR-100/100 optically reflective film) |
| Detection Range Limit Value | 3 m |
| Reference Target | H50 Reflector |
| Light Source | LED |
| Light Source Type | Modulated Visible Red Light |
| Polarization Filter | Yes |
| Spot Size | Approx. 200 mm diameter at 3 m distance |
| Divergence Angle | Approx. 4 |
| Optical Face | Straight forward |
| Ambient Light Restriction | EN 60947-5-2:2007+A1:2012 |
| Work Indicator | Green LED: Power on |
| Function Indicator | Yellow LED: Lights up when the beam is received; Flickers when stability control is insufficient; Shuts off when the beam is interrupted |
| Control Element | Sensitivity adjustment; Switches on when light is on/switches on when dark |
| Operating Voltage | 10...30 V DC |
| Maximum Ripple | 10% |
| No Load Current | < 20 mA |
| Switch Type | Changeable; Default: On |
| Signal Output | 1 NPN output, short circuit protection, reverse polarity protection, open collector |
| Maximum Switching Voltage | 30 V DC |
| Maximum Switching Current | 100 mA, impedance load |
| Voltage Drop | 1.5 V DC |
| Switching Frequency | 1000 Hz |
| Response Time | 0.5 ms |
| Ambient Temperature | -30...60 ℃ (-22 ... 140 F) |
| Storage Temperature | -40...70 ℃ (-40 ... 158 F) |
