Adaptability for Various Distances: Provides optimized spot sizes for both short and long ranges, catering to diverse application scenarios.
Spot Size at Close Range: Light spot size is approximately 6mm within a distance of 100mm, ideal for precise detection.
Spot Size at Extended Range: Light spot size is approximately 9mm within a distance of 300mm, suitable for larger target detection.
| Model number | BGD-G30NT |
|---|---|
| Detection distance | 3mm-300mm |
| Detection blind area | 5mm |
| Return gap | <10%Detection distance |
| illuminant | 650nm red modulated light |
| Operating voltage | 24V |
| Current consumption | ＜30mA |
| Load current | 100mA |
| Leakage current | ＜0.01mA No Load |
| Residual voltage | 0.8V |
| Response frequency | 300Hz |
| Reaction time | 2ms |
| Power reverse protection | There are |
| Class of protection | IP65 |
| Item | Specification list |
|---|---|
| Detection mode | Background suppression diffuse reflection type |
| Model number | BGD-G30NT |
| Detection distance | 100mm |
| Detection blind area | 5mm |
| Return gap | <10%Detection distance |
| Adjustable range | Minimum distance:<30mm,Maximum distance：>200mm(White cardstock) |
| Standard test substance | 10*10cm Black cardstock/White cardboard |
| illuminant | 650nm red modulated light |
| Spot size | 60*5mm |
| Operating voltage | 24V |
| Current consumption | ＜30mA |
| Load current | 100mA |
| Leakage current | ＜0.01mA No Load |
| Residual voltage | 0.8V |
| Response frequency | 300Hz |
| Reaction time | 2ms |
| Power reverse protection | There are |
| Output short-circuit protection | There is no |
| Class of protection | IP65 |
| Connection mode | Φ4.0*2M/4-wires/Φ4.0*5M/4-wires/ Connecting line |
