Compact Size: Half the size of a fingertip, saving installation space.
High Durability: IP65 sealing for dust and water resistance, ideal for harsh environments.
Stable Performance: Fixed, non-adjustable monitoring distance with strong interference resistance.
Small size, IP65 protection, and robust tail protection.
Fixed monitoring distance with reliable performance.
| Detection Mode | Relative form |
|---|---|
| Model Number | SC08AIR-S50N |
| Detection Distance | 0~500mm +20% |
| Standard Test Substance | Opaque object Φ3.0*0.8mm above, Φ2.0 Opaque object |
| Illuminant | 940nm Infrared modulated light |
| Hysteresis | <20% Detection distance |
| Operating Voltage | 12~24VDC +10% pulse (P-P) less than 10% |
| Load Current | 50mA |
| Repeatability | <5% Detection distance |
| Response Frequency | 300Hz |
| Output Mode | NPN.NO/NPN.NC |
| Reaction Time | 0.5ms |
| Class of Protection | IP65 |
| Trademark | Yakexi |
| Brand | Hongfei |
| Origin | China |
| Detection Mode | Relative form |
|---|---|
| Model Number | SC08AIR-S50N |
| Detection Distance | 0~500mm +20% |
| Minimum Detector | Opaque object Φ1.0*0.8mm |
| Standard Test Substance | Opaque object Φ3.0*0.8mm above, Φ2.0 Opaque object |
| Sensitivity Regulation | There are |
| Illuminant | 940nm Infrared modulated light |
| Hysteresis | <20% Detection distance |
| Operating Voltage | 12~24VDC +10% pulse (P-P) less than 10% |
| Current Consumption | <15mA |
| Load Current | 50mA |
| Leakage Current | <0.01mA (No Load) |
| Residual Voltage | <1.5VDC (load current 100mA, wire 2 meters) |
| Repeatability | <5% Detection distance |
| Response Frequency | 300Hz |
| Power Reverse Protection | There are |
| Output Short-Circuit Protection | There are |
| Output Mode | NPN.NO/NPN.NC |
| Reaction Time | 0.5ms |
| Isolation Resistance | >20MΩ (between the charging part and the housing) |
| Insulation Withstand Voltage | 1000VDC 50~60Hz 1min (between the charging part and the housing) |
| Ambient Temperature | -10~50°C (no frost or ice) |
| Ambient Humidity | 35~95% HR relative humidity |
| Ambient Illumination | Daylight: less than 2,000LX, Light: less than 1,000LX |
| Storage Temperature | -20~60°C (no frost or ice) |
| Storage Humidity | 35~95% HR relative humidity |
| Class of Protection | IP65 |
| Connection Mode | Φ3*2M/2-wires, Φ3*2M/3-wires, Φ3 Lead 150mm with M8 connector |
| Shell Material | SUS304 |
| Net Weight | Approx. 100g/102g |
