Versatile Application: Designed for a wide range of applications.
Long-Distance Detection: Detects up to 20m with through-beam, 4m with lens reflection, and 1m with diffuse reflection.
Durable and Adjustable: Long lifespan, strong interference resistance, and adjustable light intensity.
Configurable Functionality: Supports both normally open and normally closed settings.
Adjustable Brightness: Allows manual adjustment of light intensity for flexible use.Strong Interference Resistance: Ensures stable performance in environments with high electrical noise.
| Model Number | SQLSLR-P400NNC |
|---|---|
| Detection Distance | 4m |
| Illuminant | 650nm Red tone light |
| Operating Voltage | 12~24VDC +10% pulse (P-P) less than 10% |
| Load Current | 100mA |
| Repeatability | <2% Detection distance |
| Response Frequency | 200Hz |
| Output Mode | NPN.NO.NC |
| Reaction Time | 1.0ms |
| Class of Protection | IP65 |
| Trademark | Yakexi |
| Brand | Hongfei |
| Origin | China |
| Detection Mode | Specular reflection type |
|---|---|
| Model Number | SQLSLR-P400NNC |
| Detection Distance | 4m |
| Minimum Detector | Opaque objectΦ20.0mm |
| Standard Test Substance | 60*40mm reflector |
| Illuminant | 650nm Red tone light |
| Operating Voltage | 12~24VDC +10% pulse (P-P) less than 10% |
| Current Consumption | <20mA |
| Load Current | 100mA |
| Leakage Current | <0.01mA No Load |
| Residual Voltage | <1.5VDC (load current 100mA, wire 2 meters) |
| Repeatability | <2% Detection distance |
| Response Frequency | 400Hz |
| Power Reverse Protection | There are |
| Output Short-Circuit Protection | There are |
| Output Mode | NPN.NO.NC |
| Reaction Time | 1.0ms |
| Isolation Resistance | >20MΩ (between the charging part and the housing) |
| Insulation Withstand Voltage | 1000VDC 50~60Hz 1min (between the charging part and the housing) |
| Ambient Temperature | -10~50°C (no frost or ice) |
| Ambient Humidity | 35~85% RH relative humidity |
| Ambient Illumination Meter | Daylight: less than 2,000LX, Light: less than 1,000LX |
| Storage Temperature | -20~60°C (no frost, ice) |
| Storage Humidity | 35~95% RH relative humidity |
| Class of Protection | IP65 |
| Connection Mode | Φ4.0*2M/2-wires, Φ4.0*2M/3-wires, Φ4.0*2M/4-wires, Φ4.0 Lead 150mm with M8 connector |
| Shell Material | ABS+PC+PVC |
| Net Weight | Approx. 76g/78g/78.5g/190g |
